Kafka Internals as Append-Only Logs

Apache Kafka is often called a distributed commit log, but what does that mean in practice? This guide unpacks Kafka’s internal log-based architecture—covering topics, partitions, segments—and shows how these components enable high-throughput, scalable message processing.

---

🧠 Topic

• A topic is a logical container grouping messages, like a folder.
• It holds one or more append-only log files.
• Topics are split into partitions to enable parallelism and scalability.

📄 Partition

• Each partition is a single append-only log.
• It preserves message order within itself.
• Appending is a fast, sequential write to disk.
• Multiple partitions allow multiple producers and consumers to work concurrently.

📦 Segment

• Kafka divides partitions into fixed-size segments (e.g., 1 GB each).
• Each segment is an individual file stored on disk.
• New segments are created once size or time thresholds are met.
• Old segments are deleted or compacted according to configured retention policies.

🔢 Offset

• An offset uniquely identifies a message’s position within a partition.
• It starts at 0 and increments with every message.
• Consumers use offsets to keep track of their reading progress.

✍️ Producer

• Producers send data to topics and choose partitions based on:
  • A deterministic key (e.g., hash of the key), or
  • Round-robin strategy (default)
• Messages are appended in a write-ahead log fashion.

📥 Consumer

• Consumers read messages from specific topic partitions by offset.
• Kafka guarantees ordering only within partitions.
• Each consumer tracks offsets on a per-partition basis (manually or automatically).

🧱 Broker

• A broker is a Kafka server holding data.
• It manages partitions, segments, and associated index files.
• Brokers handle replication, client requests, and leadership elections.

🔁 Replication

• Partitions have one leader and multiple followers.
• Followers replicate the leader’s log in real-time.
• This replication ensures fault tolerance and data durability.

🧹 Log Compaction

• Log compaction retains only the most recent record for each key.
• Useful for topics that represent state changes.
• Compaction runs in the background and preserves the append-only nature of logs.

---

🛍️ Real-World Analogy: Kafka for User Activity Logs

Example: E-commerce Clickstream

• Topic: user-clicks
• Partitions:
  • Partition 0 → users where hash(key) % 3 == 0
  • Partition 1 → hash(key) % 3 == 1
  • Partition 2 → hash(key) % 3 == 2

Example Segment Files

/kafka-logs/user-clicks-0/00000000000000000000.log
/kafka-logs/user-clicks-1/00000000000000000000.log
/kafka-logs/user-clicks-1/00000000000001000000.log
/kafka-logs/user-clicks-2/...

Kafka Log Structure Mapping

Kafka Term	Log Analogy	Example
Topic	Directory of logs	user-clicks
Partition	Log file	user-clicks-1
Segment	Rotated chunk file	00000000000001000000.log
Offset	Line number	1234
Producer	Log appender	Appends to user-clicks-1
Consumer	Log reader	Reads from user-clicks-1 @ 1234

---

🎯 Consumer & Partition Selection

Offset is Partition-Specific

• Offset 500 in Partition 0 is completely independent from Offset 500 in Partition 1.
• Consumers must keep track of offsets for each partition separately.

How Consumers Get Partitions

1. Consumer Groups

   • Kafka automatically assigns partitions to consumers within a group.
   • Offsets are committed in the context of consumer groups.

2. Manual Assignment

   • Applications can manually assign specific partitions.
   • Offsets can be explicitly specified (e.g., from start, end, or a checkpoint).

---

Kafka’s append-only log design is the foundation of its performance and reliability. Grasping these internals empowers you to design more efficient systems, especially suited for event-driven architectures, real-time analytics, and distributed data pipelines.
